WIRING CONFIGURATION 1: RECOMMENDED BUSBAR CONFIGURATION
The recommended configuration for Rolls R48-100LFP ESS Systems uses a busbar with an external positive fuse as depicted below. Busbars should be used for all configurations with parallel batteries. Ensure cable lengths are consistent across the system, and that external cabling and busbars can withstand the maximum current from the battery as determined by your system configuration.
Note: On the Rolls R48-100LFP ESS, each terminal has a maximum pass-through current limit of 100A.
